The engine is the source of power, bringing power to modern society. While the engine must be started by a starter. The common starter is an electric starter that needs a battery to provide energy. Other starting methods like air starter, require an external system to provide energy. All of them rely on external power. Once it lacks external power, the engine is “dead”.
The mechanical starter is the ideal solution during the above situations. Cqstart spring starter, using a simple mechanical mechanism, stores the energy by compressing the springs and releases the spring’s potential energy by pulling the trip lever to turn the engine’s flywheel.
What is the mechanical spring starter?
A mechanical starter which stores the manpower energy by compressing the disc springs and releases the energy by pulling the trip lever. And then the drive pinion will drive the flywheel to rotate.
It is the ideal solution for a black start, mostly used in military, emergency rescue, firefighting, marine and some other conditions where require high reliability. It is also called mechanical spring starter, spring startup, hand starter, hand-operated spring starter.
How to fit a mechanical starter to the engine?
(1) Most of the flywheel housings have two bores. The electric starter has taken a bore. And spring starter can be installed to the other bore.
(2) If the engine only has one mounting bore, just remove the electric starter and install spring starter to the mounting bore when needed.
Advantages of mechanical spring starter
Compared to an electric starter, the mechanical spring starter is maintenance-free. And compared to other means of starting, a spring starter requires no external system such as battery, cable, air compressor, fuel tank and so on. Cqstart spring starter is waterproof, anti-corrosion, and produces no sparks. With a natural anti-explosion structure, you can use it anywhere dangerous.
